Xray hat nun den neuen Elektro 1/8 GT mit demGTXE vorgestellt.
Features – Part 1.
- New aluminum center spur gear collar – Swiss 7075 T6
- All-new flat 3mm aluminum chassis with increased battery cooling & completely flat profile, including side sections, eliminating front kick-up for lower CG
- New composite front bumper specifically designed for the flat chassis layout
- New lightweight foam bumper for reduced weight
- New front bulkhead adapted to the flat chassis configuration
- New rear bulkhead designed to accommodate upper center top deck mounting
- Stronger, lowered motor mount for improved service access & reduced CG
- Rear aluminum center shaft stand for increased drivetrain stability
- Upper carbon top deck for steering posts integrated with one-piece top deck
- Aluminum holder supporting the carbon top deck for improved rigidity
- One-piece carbon top deck from front to rear for enhanced chassis stiffness & consistency
- Aluminum rear brace supporting the top deck for improved rigidity & stability
- Receiver box for cleaner layout & improved electronics protection
- Carbon ESC plate with increased space for speed control & cooling fan
- Center driveshaft assembly featuring HUDY special hardened pins for maximum durability
Features – Part 2.
- Lower front & rear shock towers with dual shock mounting rows
- Front aluminum shock adapter with 2 positions for increased stability & improved corner speed
- Rear aluminum shock adapter with 3 positions for increased stability & improved corner speed
- Reinforced front suspension arms compatible with carbon arm stiffeners
- Rear suspension arms – X-hard
- Front carbon arm stiffeners improving drivability & increasing corner speed
- Carbon battery holders mounted on aluminum posts for secure battery positioning
- Aluminum A arm holders designed for flat chassis
- Rear D suspension holder features refined design
- Aluminum 6° C-hubs (L+R) allowing extended front shock mounting positions
- Titanium steering turnbuckles
- Titanium front upper turnbuckles
- Titanium rear turnbuckles
- Aluminum steering blocks
- Aluminum rear uprights with carbon holders
- Front springs: 2 dots + 1 stripe
- Front anti-roll bar: 2.8mm
- Rear anti-roll bar: 2.8mm
Hier die Oräsentation: www.teamxray.com/GTXE
Quelle: teamxray , Hudy und Xray Team Germany
